Download#

You can download the prc_blender.zip addon from Github via

Prerequisites#

Version requirements#

• Blender 5.0.0 or later. Earlier versions (4.3 and below) are not supported — the add-on uses Blender 4.4+ Geometry Nodes APIs and won’t load on older builds.
• Blender 5.2.0+ is required for the Insert Code action node, which depends on string-typed Geometry Nodes attributes that landed in 5.2. On 5.0 / 5.1 every other feature works; the Insert Code entry simply doesn’t appear in the Add menu.
• Platforms: Windows x64, Linux x64, macOS arm64, macOS x64. The bundled gRPC / protobuf wheels target CPython 3.13 (the interpreter shipped with Blender 5.x).

Other requirements#

• PRC server running on https://127.0.0.1:5001.
• The prc_blender add-on installed and enabled (Edit → Preferences → Add-ons).

After enabling the add-on, the Parametric Robot Control panel appears in the 3D Viewport’s N-panel sidebar.

1. Connect to the Robot#

In the Robot Setup box (gear icon):

1. Set Client ID (any stable string, default PRC_Blender).
2. Pick a Driver (e.g. KUKA KSS (KRL)). The Robot dropdown auto-filters to that brand.
3. Pick a Robot from the filtered list.
4. (Optional) In the Tool box, set the TCP — Position (mm) and Rotation. The rotation fields adapt to the driver convention (ZYX degrees for KUKA, RPY for NEURA, axis-angle for UR, quaternion for ABB). The Tool ID determines which dictionary slot the TCP lives at.
5. Click Setup Robot.

The first run downloads the robot mesh from the server and creates A0..A6 link objects, the TCP axis-arrow marker, the Tool Empty (parented to TCP — drop your own tool geometry under this Empty and it will follow the TCP), and the PRC_Program carrier object.

After setup, identity / driver / robot / tool fields lock until you Disconnect. To change the robot model: Disconnect, edit, Setup Robot again.

2. Run the Default AXIS Motion#

The first time you connect, also click:

• Generate Geometry Node Groups — creates all PRC node groups (motion commands, helpers, modifiers, task) and stamps the starter tree on the PRC_Program carrier.

The starter tree is:

AXIS Move 1 ──┐
              ├── Join Geometry ── PTP Motion Group ── PRC Task ── Output
AXIS Move 2 ──┘

AXIS Move 2 is pre-set to A1 = 45° so the simulation produces a visible sweep.

Now in the panel:

1. Click Load Task from Geometry Nodes. The status line confirms the task duration. A toolpath tube appears in the viewport (white = OK, red = alarm).
2. Drag the Simulation slider — the robot animates along the toolpath.

To preview a different sweep, edit the A1 / A2 / etc. inputs on the AXIS Move nodes and hit Load Task again. (Or enable Auto-simulate, see Section 9.)

3. Building Custom Programs — the Add Menu#

Inside the PRC_Program Geometry Nodes tree, press Shift + A and find the PRC submenu (kinematic icon). Sections:

The pipeline shape is always the same:

[motion commands or helpers] → Join Geometry → [optional modifiers] → PRC Task → Output

4. Motion Commands#

AXIS Move (joint-space)#

Inputs: A1..A6 (degrees), Speed (KUKA percentage). Each instance produces one joint-target waypoint.

PTP Move#

Inputs: Object (optional Empty whose world transform drives the waypoint), Position, Rotation (added on top of Object’s transform), Speed, Posture.

LIN Move#

Inputs: Object, Position, Rotation, Speed (m/s).

Pattern: drop several motion commands → Join Geometry → wrap in a Motion Group → PRC Task.

LIN_1  ──┐
LIN_2  ──┤── Join Geometry ── PRC Cartesian Motion Group ── PRC Task ── Output
LIN_3  ──┘

Mix motion types by placing each batch into its own motion group, then joining the groups with plain Join Geometry before Task. Each Cartesian Motion Group / PTP Motion Group instance becomes a separate motion group in the program.

PTP MG  ──┐
LIN MG  ──┤── Join Geometry ── PRC Task ── Output
LIN MG  ──┘

Plain Join Geometry is all you need to combine multiple Motion Groups, Action Groups, or Curve Helpers — each instance is automatically tagged so the reader keeps them as separate groups in the program.

Don’t mix motion types inside a single Motion Group. A PRC PTP Motion Group may only contain AXIS and PTP commands; a PRC Cartesian Motion Group may only contain LIN commands. The reader rejects mismatched wiring with a clear error message.

5. Helpers (point a curve / mesh / object at the helper, get a complete motion group)#

Curve Helper#

Inputs: Curve (Object), Divisions (Int, per spline), Orientation (optional Object), Speed (m/s), First as PTP (Bool), Posture (Int).

Each spline in the source curve becomes its own motion group. A 3-spline curve with Divisions=10 produces 3 motion groups of 10 waypoints each.

• First as PTP = False → N Cartesian motion groups, all LIN. One group per spline.
• First as PTP = True → For each spline, two motion groups: a PTP Motion Group containing only the first sample, then a Cartesian Motion Group with the remaining samples as LIN. A 3-spline curve emits 6 motion groups (3 PTP + 3 CP) in spline order.

Mesh Path Helper#

Inputs: Mesh (Object), Orientation (Object), Use Normal (Bool), Flip Normal (Bool), Speed, PTP (Bool), Tool ID, Posture.

Vertex order = path order. Use this for edge loops, polylines, or any mesh whose vertex ordering matters.

• Use Normal = False → orientation taken from the Orientation object’s rotation.
• Use Normal = True → orientation derived from each vertex’s normal (works on faces). Local +Z aligns to the normal; rotation around the normal is arbitrary — chain PRC Orient to Point after this if you need controlled X.
• PTP = True wraps in a PTP Motion Group, else Cartesian Motion Group.
• Tool ID picks which entry of the robot’s tool dictionary the resulting motion group runs with. Leave at 0 to use the default tool you configured in the panel; set to a non-zero number to reference an additional tool you’ve registered on the server.
• Posture only applies when PTP = True — it’s the joint-configuration code (zero-padded to 3 digits at submit time, e.g. 010) used by the PTP waypoints.

Animation Helper / Grease Pencil Helper#

Both are thin wrappers for discoverability. Point Source at the baked path mesh you create via the panel’s Animation Source / Grease Pencil Source sub-panels (see Section 8).

6. Modifiers#

Approach Retract#

Inputs: Geometry (one or more motion groups), Offset Start (m), Offset End (m).

Duplicates the first and last waypoint of each Cartesian motion group in the input, offset along world +Z. The new waypoints inherit the source point’s prc_motion_group, so they stay inside the same group — they just bracket it. PTP motion groups and Action groups in the same input pass through untouched. A 3-CP-group input gets 3 approach + 3 retract points; PTP groups in the same stream contribute zero extra waypoints.

Mixed input is therefore safe: drop a Curve Helper output (with First as PTP enabled) or a Join Geometry of mixed PTP + CP groups straight in, and only the CP segments grow approach/retract flanks.

Set either offset to 0 to disable that side. World +Z is used (rather than the per-vertex tool-Z) so orientation changes inside a single motion group don’t tilt the approach direction.

LIN moves → Join → CP Motion Group ─┐
LIN moves → Join → CP Motion Group ─┼── Join Geometry ── Approach Retract ── PRC Task
LIN moves → Join → CP Motion Group ─┘

Orient to Point#

Inputs: Geometry, Target (Object), Face Away (Bool).

For every waypoint, rotates the orientation around its local +Z so local +X points at (or away from) the Target object. Useful for:
- Spray nozzles aimed at a workpiece centre.
- Welding torches whose front edge tracks the seam direction.
- Camera-on-flange setups pointing at a focal subject.

Place after motion groups; the helper preserves all other attributes.

7. Actions (Blender 5.2+)#

Insert Code#

Inputs: Code (String), Is Comment (Bool).

Drop a single inline robot-program line (KRL, RAPID, etc.) into the program flow.

... motion groups ...  ─┐
                        ├── Join ── PRC Task ── Output
PRC Insert Code     ───┤

For multiple consecutive inline-code instances, just join them.

8. Auxiliary Sources (collapsible panels under the main panel)#

The three sub-panels at the bottom of the main panel (collapsed by default) generate path meshes that you point your Helper nodes at, or play back without PRC.

Animation Source (ANIM icon)#

Bakes any animated Object’s motion over a frame range into a path mesh.

1. Pick an animated Object (typically an Empty with keyframes).
2. Set Frame Start / End / Step.
3. Choose Mode: All LIN, All PTP, or First PTP, rest LIN.
4. Set Speed (m/s for LIN), Tool ID, and Posture (PTP only).
5. Click Bake Animation — produces PRC_AnimPath_<name>.

In the GN tree: drop a PRC Animation Helper, point Source at PRC_AnimPath_<name>, join into Task.

Grease Pencil Source (pencil icon)#

Bakes a Grease Pencil drawing into a path mesh with tangent-derived orientations.

1. Pick a Grease Pencil object.
2. Set Layer Index / Frame Index.
3. Optionally set Sample Distance (resample by arc length, 0 = use raw stroke points).
4. Choose Orient: Tangent + World Up or Tangent + Up Object (point the Up Object slot at any object — its +Z becomes the up reference).
5. Choose Mode, set Speed, Tool ID, Posture.
6. Click Bake Grease Pencil — produces PRC_GPPath_<name>.

Drop a PRC Grease Pencil Helper in the GN tree, point at the baked mesh.

Robot Animation (kinematic icon)#

Bakes the simulated robot motion into a self-contained Blender animation that plays back without PRC running.

Prerequisite: connected, with a task loaded (status line shows duration).

1. Set Target Name (default PRC_RobotAnim). If a collection of this exact name already exists, its contents are replaced; otherwise nothing in the file is touched.
2. Read the live label: Duration: …s · FPS: … · Frames: …. Override FPS Override if you want a different sampling rate (0 = use scene FPS).
3. Set Frame Start (default 1).
4. Toggle Set Scene Range to expand the scene’s playback range over the bake.
5. Click Bake Robot Animation.

The resulting collection is shareable, renderable, and exportable without PRC installed.

Studio Environment (scene icon)#

Builds a symmetric, 360°-friendly product-shot studio around the robot — a cyclorama backdrop (flat floor → curved corner → vertical wall), an overhead key light, and a configurable ring of rim/fill lights. Sized off the robot’s bounding box.

Prerequisite: Setup Robot has run (so the PRC Robot collection exists).

1. Set Floor Radius (multiplier on the robot’s horizontal extent) and Wall Height (multiplier on the robot’s height).
2. Set Key Power (overhead light, watts), Rim Count (lights in the ring), and Rim Power (per-light watts).
3. Click Build Studio Environment — produces a PRC_Studio collection containing the backdrop and a nested PRC_Studio_Lights sub-collection. Re-running rebuilds cleanly.

9. Live Workflow#

Auto-simulate on Edit#

In the Task & Simulation box, toggle Auto-simulate on Edit. While on, any change to PRC_Program’s geometry (a node socket, an upstream Empty’s transform, etc.) re-submits the task to PRC after a brief debounce. Disable for big programs where the resubmit cost is noticeable; the manual Load Task button still works as a force-reload-now.

Status indicators#

Above Task & Simulation:
- Toolpath valid (green check): last task simulated cleanly.
- Toolpath has alarms (red banner): part of the path triggered an alarm.
- No toolpath loaded (dim dot): nothing submitted yet.

Disconnect#

Stops the feedback stream, resets connection state, unlocks Robot Setup / Tool fields. Existing A0..A6, TCP, Tool, and PRC_Toolpath_* objects survive — Setup Robot reuses them.

10. Example: Putting It All Together#

Goal: spray-paint along three offset polylines on a curved surface, with safe approach/retract on each pass, and a baked animation for client review.

1. Setup Robot, configure your tool TCP, Setup Robot.
2. Generate Geometry Node Groups.
3. In the scene: a Curve object with three splines tracing the paint passes, plus an Empty whose +Z is the desired tool axis.
4. Open the PRC_Program GN tree and wire:

Curve (3 splines) ──► PRC Curve Helper ──► PRC Approach Retract ──► PRC Task ──► Output
                       │                       │
       Orientation Empty                  Offset Start = 0.05
       Divisions    = 30                  Offset End   = 0.05
       Speed        = 0.05
       First as PTP = ☑
       Posture      = 10

1. Click Load Task. Drag the simulation slider to verify each pass.
2. Toggle Auto-simulate on Edit; tweak Divisions / Speed interactively until the path looks right.
3. Open the Robot Animation sub-panel, set Target Name = paint_pass_v1, click Bake Robot Animation.
4. Save the .blend. The paint_pass_v1 collection is now a self-contained baked animation — render it, share it, export to glTF/Alembic, all without needing PRC running.

That’s the full workflow.
